| Seat height | 40 cm
|
| Body length | from 1,50 m
|
| Frame & front fork | chrome-molybdenum
|
| Weight | 14.9 kg excl. carrier
|
| Front suspension | M5 Mono ShockŪ, M5 Duo ShockŪ or M5 Monoblade unsuspended front fork
|
| Rear suspension | hydraulic. Option: Rock Shox SID air/air suspension
|
| Shifters | SRAM Rocket 9.0
|
| Equipped with | Campagnolo Veloce 2x9 or 3x9
|
| Brakes | Side-pull or V-brakes (optional: Magura hydraulic rim brakes)
|
| Wheels | 36 spoke half high aero rims
|
| Finish | double metallic powder coating with transparant top layer, in several colours.
|
| Optional | light weight aluminum carrier (600 grammes) with integrated rear light (LED)
|
| Optional | Tailbag for Shock Proof, 65 litres luggage capacity. See right picture below and the M5 Carbon Specials.
|
)
The version of the Shock Proof with ETRTO 406 mm wheels. They provide the possibility to use tyres from 25 up to 50 mm. Special features of the 406 version: carbon fenders for larger tyres available. 406 version only with M5 Duoshock® front fork, no unsuspended version.)
)
